Galaxy Trek GTU Compact UHF Dual Channel Wireless Mic Solution
Galaxy Trek GTU Wireless Portable Microphone system features a 160-foot range and UHF frequency wireless transmitter options with a choice of...
This product must be purchased through our retailer network
Choose a RetailerGalaxy Trek GTU Wireless Portable Microphone system features a 160-foot range and UHF frequency wireless transmitter options with a choice of handheld, headset, or lavalier mics. Additionally, the user-friendly compact dual-mic receiver enables the use of any two of the microphone transmitter options simultaneously.
The Galaxy Trek GTU incorporates Auto Match Pairing to connect transmitters to an open channel. Simply turn on the Receiver and 1 or 2 Transmitters to seamlessly sync. Each transmitter has its own 30 selectable channels Plug the Galaxy Trek Receiver into the 1/4" input of active speakers, mixers, cameras, and more for instant wireless connectivity. The Galaxy Trek GTU system also includes a 1/4" to 1/8" adapter. Dual Mic systems are available in a variety of configurations, from handheld, headset, or lavalier microphones. Mix and match your system.
Combine the Trek GTU with a powered loudspeaker to create a versatile wireless PA system for classroom instruction, sports coaches, corporate and trade-show presenters, aerobics instructors, auctioneers, religious ceremonies, weddings, and more.
● Easy Set-Up
● Compact Light-Weight Design
● 160 ft Operating Range
● Dual Microphone Wireless Receiver (Works with 2 Wireless Transmitters Simultaneously)
● Rechargeable Receiver
● UHF Wireless Transmission
● Full Range Microphone
● Volume Control On Transmitters
● 60 Selectable Channels 30 per transmitter
● 6 Hours Battery Life
Galaxy Trek GTU Compact UHF Dual Channel Wireless Mic Solution Specifications
| GTU System | |
|---|---|
| Pairing | Auto-Match Pairing - Simply turn on the Receiver and 1 or 2 Transmitters and they will automatically sync. Plug the Receiver into a powered speaker and you’re ready to be heard. |
| Frequency Response: | 80Hz-15KHz |
| Frequency Range: | 30 channels in Handheld, 30 channels in Body Pack |
| S/N Ratio: | >60dB |
| THD | 0.5% (1khz) |
| Sensitivity | -70dbM |
| Operating Range | 160ft (50 meters)* |
| RF power | 20mW |
| Bandwidth: | 60 MHz |
| Frequency Range | 524.500 MHz - 594.500 MHz 30 channels in Handheld 30 channels in Body Pack |
| Dual Channel Receiver GTU-DREC: | |
| Controls: | On-Off Power Switch |
| Audio Output | 1/4" Output |
| Indicators: | Power and Pairing LEDs |
| Receiving Sensitivity | < 2uV |
| Spurious Rejection | > 40dB |
| Audio output Impedance | 600 Ohm |
| Audio output Level | 0-0.5V |
| Power Supplied By | Lithium Ion Battery (Included) Mini USB Charging Input |
| Input Power | 5VDC USB |
| Dimensions | 4.5" x 1.4” x 1" (114.3x35.5x25.4 mm)(HxWxD) |
| Weight | 2.8oz (79 g) with battery |
| Transmitters: | GTU-HH28 Handheld GTU-MBP28 Body Pack |
| Controls | On-Off Power Switch / Volume Control / Channel Select |
| GTU-HH28 Handheld Mic Element | Dynamic Cardioid Capsule |
| GTU-MBP28 Body Pack Mic Input | TRS 3.5mm |
| Indicators | Backlit Display Shows Battery Level, Frequency, Channel, & RF |
| Frequency Stability | +- 0.005% |
| RF power | <30mW |
| Spurious Rejection | > 40dB |
| Peak Deviation | +- 75Khz |
| Modulation | UHF |
| Power Supplied By | (2) AA Alkaline or Rechargeable Batteries (Not Included) |
| Handheld Dimensions | 9.75" x 2.06" x 2.06" (248x52x52 mm)(HxWxD) |
| Handheld Weight | 9.2 oz (261 g) (Without Batteries) |
| Body Pack Dimensions | 4.25" x 2.7" x 1.17" (108x68.5x30 mm)(HxWxD) |
| Body Pack Weight | 2.4 oz (68 g) (Without Batteries) |
| Included Accessories | 1/4 inch to 1/8 inch Adapter USB Charging Cable |
| *Actual range depends on RF signal absorption, reflection, interference, and battery characteristics. |
Videos
Reviews
Suggested Products
GPS-8
The Galaxy Audio GPS-8 full range personal monitor PA system packs huge sound while remaining compact and versatile. The GPS-8 is a full range...
TQ8X Traveler Quest 8X Economical Portable Rechargeable PA Speaker System
The Traveler Quest 8X is a versatile, compact, portable lightweight, cost-effective PA system. The Galaxy Audio TQ8X is a remote battery-powered...
TV8 Traveler 8 All-Inclusive Battery Powered Portable Wireless PA Systems
The Galaxy Audio Traveler (TV8) is an AC/battery-operated portable PA system. This compact system features an 8" woofer, 1" horn, 80-watt amplifier,...
TV10 Traveler 10 All-Inclusive Battery Powered Portable Wireless PA Systems
The Galaxy Audio Traveler (TV10) is an AC/battery operated, wireless portable PA speaker system. The Traveler is designed for people who...
FCC Consumer Alert for Wireless Microphones (U.S.)
Most users do not need a license to operate this wireless microphone system. Nevertheless, operating this microphone system without a license is subject to certain restrictions: the system may not cause harmful interference; it must operate at a low power level (not in excess of 50 milliwatts); and it has no protection from interference received from any other device. Purchasers should also be aware that the FCC is currently evaluating use of wireless microphone systems, and these rules are subject to change.
For more information, call the FCC at 1-888-CALL-FCC (TTY: 1-888-TELL-FCC) or visit the FCC’s wireless microphone website at fcc.gov/cgb/wirelessmicrophones
